label die cutting machine

1.HX-320/420CLabel Die Cutting Machine( with slitting function) Features: 1.HX-320C slitting machine with rotary die-cutting function is a new product, it equipped with high accurate rotary die-cutting system. 2.This machine is suitable for blank adhesive labels. 3.Die-cutting, slitting can be finished in one process. 4.It has the function of automatic meter counting, automatic stopping, web guiding by photoelectric eye. 5.The machine has the characteristics of compact structure, fast speed, high efficiency , easy operation, accurate slitting , steady running etc. Main technical parameters: Slitting Speed 75m/min Die Cutting Speed 70m/min Max Web Width 320mm Max Unwinding Diameter 500mm Max Rewinding Diameter 480mm Die Cutting Length 178mm-470mm Overall Diameter 1.32mx1.02mx1.52m Machine Weight 600KG rotary die cutting device Slitting knife device HX-350B/420B Multi-functional Automatic Die Cutting Machine Feature: The machine enjoys multi-layer sticking ,partial sticking, feeding- filming-die cutting- waste draining- slitting-rolling, all of them are completed by the computer control by one turn. Applicable Material: Sticky production: diversified electronic, electrical appliance, special mobile phone rubber cushion, silicon rubber cushion, magic tape, electric conductive tape, powerful double side adhesive , SUNEAST 3M, SONY special binding products.Dustproof materials: cosmetic cotton, camera cotton, high density sponge, filtering sponge, dust net and non-woven fabricShock absorbing products: EVA tape, rubber cushion, PORON cushion,3M, inflammable retardant EVA, high foamInsulation, EMI : fireproof paper, aluminum foil, copper foil, PVC,PET, brown paper, sponge sheath, pearl cotton sheathHeat insulation material : silicon sheet, transparent mica, fiber cloth, heat insulation cotton (fabric) Main technical parameters: Model 350B 420B Cutting speed 20-200 (t/m) 20-200 (t/m) Max unwinding diameter 450mm 450mm Max web width 320mm 420mm Max mould cutting area 320x380mm 420x420mm Orientation accuracy ±0.10mm ±0.10mm Motor power 3kw 4kw Power voltage 220v±10% 380v±10% Machine weight 2200kg 2800kg Measurement 2600x950x1400mm 2600x1050x1800mm flat bed die Piece cutting knife HX-320/420AAutomaticdiecuttingmachineforselfadhesivelabels MainTechnicalParameters: Model: HX-420A DieCuttingSpeed:20-180m/min MaxPuttingDiameter:650mm MaxWebWidth:420mm MaxDieCuttingWidth:400mm MaxDieCuttingLength:290mm PositioningPrecision:0.10mm TotalPower:3.5kw PowerSupplyVoltage:380v MachineWeight:2000kg Export information 1.Export packing : wooden case 2.Certifications: We have passed ISO9001 and CE certificationin 2009 3.We have 10years export experience in cutting machine Our advantage: 1.The guarantee is one year ! 2. After service: A reply within 24 hours 3. Export experience for 10 years and manufacturing experience for 30years in this field . 4. The relative video are available
